Commercial Refrigerator Manufacturer and Supplier

Profile

Western Refrigeration is India’s largest commercial refrigeration equipment manufacturer. With 4 state-of-the-art factories & a manufacturing capacity of over a million units per year, we offer a wide range of reliable & energy-efficient commercial refrigerators to our customers.

WESTERN REGRIGERATION PVT. LTD.

The largest manufacturer of commercial refrigeration equipment in india.

Western Refrigeration Pvt. Ltd. came into existence in 1972 by our founder Chairman Mr. Bhupinder Singh. We first started as a trading company, incorporating and supplying air-conditioning and refrigeration parts to large companies in our industry.

Based on our association with the refrigeration industry and knowledge of importation we returned into the importation of beverage dispensers and coolers from 1995 onwards. Western soon set-up its first cooler plant in Shahpur, Maharashtra in 1997 and then ventured into manufacturing of horizontal coolers and freezers segment with its second plant in Silvassa, India in the year 2001. Over the years, Western has expanded its business and now has operations spread across its 16 offices in India.

Western was the 1st manufacturer in India for Visi-coolers and has since become one of the largest manufacturers of commercial refrigeration equipment in India. Western in 2014 set up a new Greenfield facility in Sanjan, Gujarat which is the largest plant of its kind in South-east Asia with an installed capacity of over 1,000 units per day. Western today has a cumulative capacity of 3,96,000 units per annum and export to 45 countries spread over Asia, Indian Subcontinent and Africa

Western has been a pioneer in use of Carbon Di-oxide as a refrigerant on its equipment and on development of Solar powered coolers. Western is also one of the first companies to start manufacturing dispensers in India and few other stainless steel equipment for the quick service restaurant industry

Due to its investment on new technology and new facilities, Western has grown at a CAGR of 30% for the last 10 years with almost 35% of our sales coming from exports.

Certification

Western Equipments is certified
ISO 45001:2018, ISO 20400:2017, ISO 14001:2015, ISO 9001:2015 company.

Product Range

Providing complete value-adding solutions for our customers

SRC200-GL

External Dimension (mm)	514 (W) x 549 (D) x 1265 (H)
Gross Vol	167 ltrs.
No of Shelves	03 nos

NEW
LAUNCH

Data Sheet

VISI Cooler

SRC200-GL

Commercial Refrigeration

Very high ambient and lower energy norms

Safety compliant as
per IEC norms

Ingress protection
class IP 24

Easy Service

LED
Wheels/ Legs (Roller)
Adjustable Shelves
Inbuilt Door Handle
Changeable Gasket
Customized Branding
Wider Display

Technical Specifications

External Dimension (mm): 514 (W) x 549 (D) x 1265 (H)
Internal Dimension (mm): 434 (W) x 454 (D) x 850 (H)
Gross Vol: 167 ltrs.
No of Shelves: 03 nos.
330ml cans 500ml Pet

Capactity 166 nos. 83 nos.

Facing 06 nos. 06 nos.
Container Loading 20’ FCL 40’ FCL

27 units 60 units
*Wider Display | *Improved Energy Efficiency | *Maintenance Free Condenser | *LED Lighting

Specifications

R134a refrigerant & 100% CFC Free Cyclopentane insulations.

NWHF225G

Gross Volume	226.0 Liters
External Dimensions (mm)	760 (W ) x 695 (D) x 795 (H)
No. of Basket	01 no.

NEW
LAUNCH

Data Sheet

Deep Freezer

NWHF225G

Commercial Refrigeration

High Ambient

Safety Compliant

Improved Energy Efficiency

Quiet Compressor

Lock And Key arrangement

Low E coating on Glass

High Ambient – Glass Top
Safety Compliant
Improved Energy Efficiency
Quiet Compressor
Lock And Key arrangement
Low E coating on Glass

Technical Specifications

Gross Volume: 226.0 Liters
External Dimensions (mm): 760 (W ) x 695 (D) x 795 (H)
Internal Dimensions (mm): 630 (W) x 530 (D) x 677 (H)
Temperature range: -17˚C to -22˚C
Insulation: 60 mm Polyurethane
No. of Basket: 01 no.

HRW-77MS4 / LS4

Gross Volume	628 liters
Temperature Range	-2°C to 12°C
Net Weight	107 kg

NEW
LAUNCH

Data Sheet

Upright Chiller

HRW-77MS4 / LS4

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

Basic Model
Half Glass
GN Suitable
Basic Long Door
Long Door GN Suitable
Hygienic and easy to clean
Automatic closing doors
Reliable quality
Full-height handle
Rounded corners

Technical Specifications

Gross Volume: 628 Liters
Net Weight: 116 kg
External Dimensions: 700 (W) x 818 (D) x 2050 (H - with 150mm leg)
Internal dims (mm): 596 (W) x 700 (D) x 1505 (H)
Temperature Range: -2°C to 12°C
Shelf: 4 nos. of shelves
Refrigerant: R134a / 245 gram
Power Supply: 230V AC / 50Hz
Heat Rejection: 0.641 kW
Temperature control: Electronic
Compressor Capacity (Watt): 429 W

Note:
Input voltage should be ± 6%
Operation condition 5°C to 43°C

NWHS550G

Gross Volume	585.5 Liters
External Dimensions (mm)	1650 (W) x 695 (D) x 1275 (H)
No. of Basket	04 nos

NEW
LAUNCH

Data Sheet

Deep Freezer

NWHS550G

Commercial Refrigeration

High Ambient

Safety Compliant

Improved Energy Efficiency

Quiet Compressor

Lock And Key arrangement

Low E coating on Glass

High Ambient – Scooping Parlor
Safety Compliant
Improved Energy Efficiency
Quiet Compressor
Lock And Key arrangement
Low E coating on Glass

Technical Specifications

Gross Volume: 585.5 Liters
External Dimensions (mm): 1650 (W) x 695 (D) x 1275 (H)
Internal Dimensions (mm): 1530 (W) x 530 (D) x 722 (H)
Temperature range: -17˚C to -22˚C
Insulation: 60 mm Polyurethane
No. of Basket: 04 nos.

RTW-150MS4/LS4

Gross Volume	415 liters
Temperature Range	-2°C to 12°C
Net Weight	122 kg

NEW
LAUNCH

Data Sheet

Two Door
Under Counter

RTW-150MS4/LS4

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

Basic Model
With Splash
Hygienic and easy to clean
Automatic closing doors
Reliable quality
Full-height handle
Rounded corners

Technical Specifications

Gross Volume: 415 Liters
Net Weight: 112 kg
External Dimensions: 1500 (W) x 750 (D) x 850 (H - with 150mm leg)
Internal dims (mm): 1132(W) x 630 (D) x 588 (H)
Temperature Range: -2°C to 12°C
Shelf: 4 nos. of shelves
Refrigerant: R134a / 260 grams
Power Supply: 230V AC / 50Hz
Heat Rejection: 0.56 kW
Temperature control: Electronic

Note:
Right Side Condensing Unit Available
Input voltage should be ± 6%
Operation condition 5°C to 43°C

WHFG200S

Gross Volume	117.0 Liters
External Dimensions (mm)	940 (W) x 640 (D) x 785 (H)
No. of Basket	NA

NEW
LAUNCH

Data Sheet

Deep Freezer

WHFG200S

Commercial Refrigeration

High Ambient

Safety Compliant

Improved Energy Efficiency

Quiet Compressor

Lock And Key arrangement

Low E coating on Glass

High Ambient - Freezer on Wheels
Safety Compliant
Improved Energy Efficiency
Quiet Compressor
Lock And Key arrangement
Low E coating on Glass

Technical Specifications

Gross Volume: 117 Liters
External Dimensions (mm): 940 (W) x 640 (D) x 785 (H)
Internal Dimensions (mm): 455 (W) x 455 (D) x 570 (H)
Temperature range: -17˚C to -22˚C
Insulation: 60 mm Polyurethane
No. of Basket: NA

Ice Maker SRM 80 A

Net Weight (kgs)	56.5 kg
Dimensions (W x D x H) (mm)	660 x 670 x 1050 mm
Storage Capacity (kgs)	31.4 kg

NEW
LAUNCH

Data Sheet

Ice Maker

SRM 80 A

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

Technical Specifications

Ice Shape (mm): Rhombic Cube (22 x 22 x 22)
01. Ice Production/24 Hrs ( kgs): 80 kgs AT 10 Deg C/WT 10 Deg C
02. Ice Production/24 Hrs ( kgs): 72 kgs AT 21 Deg C/WT 15 Deg C
03. Ice Production/24 Hrs ( kgs): 57 kgs AT 32 Deg C/WT 21 Deg C
Storage Capacity (kgs): 31.4 kg
Dimensions (W x D x H) (mm): 660 x 670 x 1050 mm
Net Weight (kgs): 56.5 kg
Electricity: 220-240V/1N/50Hz; 450 Watts

Note:
Input voltage should be ± 6%
Operation condition 5°C to 43°C
*If you need other combinations please feel free to ask us

Pastry Cabinet PTW12

Gross Volume	500 Liters
Temperature Range	2°C to 10°C
Net volume	435 litre

NEW
LAUNCH

Data Sheet

Pastry Cabinet

PTW12

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

Adjustable glass shelves
Faster pull down
Heated glass – Front and top
Electronic temperature control
Stainless steel inner bottom shelf
Castor wheel for easy movement
LED lamps for individual shelves
On/off switch for lights and glass heater
Wire on Tube condenser for low maintenance

Technical Specifications

External dim (mm): 1200 (W) x 665 (D) x 1235 (H)
Internal dim (mm): 1110(W) X 570(D) X 710(H)
Gross volume (litre): 500
Net volume (litre): 435
Temperature range: 2°C to 10°C
No load Pull down: 1 hour 08 minutes
IPDT: N/A
Evaporator Type: Forced (Fin & Tube)
Condenser Type: Forced, Wire and Tube type
Compressor Type: HERMETIC
Compressor cooling Capacity: 601 W
Temperature control: Electronic controller

Note:
Ambient unit (no refrigeration)
Hot unit (50°C)

RBW-135

Gross Volume	349 Liters
Temperature Range	0°C to 10°C
Net weight	94 kg

NEW
LAUNCH

Data Sheet

Back Bar

RBW-135

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

Hygienic and easy to clean
Reliable quality
Rounded corners

Technical Specifications

External Dimensions: 1350(W) x 545 (D) x 900 (H)
Gross Volume: 349 Liters
Rated voltage (VAC): 230
Rated frequency (Hz): 50Hz
Net weight (Kg): 94
Refrigerant number Mass(g): R134a / 155
Rated wattage (W): 343
Temp. Range(C): 0 to 10°C
Bottle Loading: 236 nos Pint bottles

Note:
Input voltage should be ± 6%
Operation condition 5°C to 43°C

SRF900

Gross Volume	762 Liters
Dimensions (mm)	920 (W) x 780 (D) x 2128 (H)
Shelves	10 nos.

NEW
LAUNCH

Data Sheet

VISI Cooler

SRF900

Commercial Refrigeration

Very high ambient and lower energy norms

Safety compliant as
per IEC norms

Ingress protection
class IP 24

Easy Service

LED
Illuminated Canopy
Wheels/ Legs (Roller)
Adjustable Shelves
Inbuilt Door Handle
Changeable Gasket
Customized Branding
Wider Display

Technical Specifications

Gross Volume: 762 Liters
Dimensions (mm): 920 (W) x 780 (D) x 2128 (H)
Shelves: 10 nos.
Temperature: <-17.0°C
Container : 40’ – 36
Loading: 20’ – 18

HRSW-126

Gross Volume	988
Temperature Control	0°C to +12°C
No load Pull down	50 minutes

NEW
LAUNCH

Data Sheet

Upright Static

HRSW-126

Special coated evaporator for long life

Cleanable and replaceable door gaskets

Perfect defrost for efficient cooling

Customer friendly design

*Cabinet Lamp optional

Technical Specifications

External dim (mm) with 90 mm leg : 1200 (W) x 750 (D) x 1890 (H)
Internal dim (mm) : 1100(W) X 640(D) X 1416(H)
Gross volume (litre) : 988
Net volume (litre) : 931
Temperature range : 0°C to +12°C
No load Pull down : 50 minutes
IPDT : 24 hours
Energy @ 32.2deg C (65% RH) : 6.01 kWh/24hrs
Evaporator Type : Skin Type Evaporator
Condenser Type : Forced, Wire On Tube type
Compressor Type : HERMETIC
Compressor cooling Capacity : 935W
Temperature control : By Mechanical Thermostat
Construction : All SUS430

View All Products

Factory

Shahpur Plant (Maharashtra)

In early 1997 WESTERN Refrigeration decided to setup a production facility for the manufacturing of Visi-Coolers primarily to cater to the requirement of Coca-Cola India. This plant started commercial production in August 1997 and is located 90kms north of Mumbai at Shahpur. This plant has an installed capacity of over 96000 units p.a. The plant employs over 200 people and first of its kind in India to use Cyclopentane Insulation (CFC Free ) technology for the manufacture of Refrigeration Equipment’s.

Silvassa Plant (Gujarat)

In mid 1999 WESTERN decided to setup their second plant at Silvasa which is 160km from Mumbai. This plant also has an installed capacity of over 55000 units p.a. and currently produces different models of Visi-Coolers, Deep-Freezers, Ice-Cream Conservators, and Beverage Dispensers under license from Lancer Corporation (U.S.A). Our flexible production system in this plant has helped us to add more products to our folio.

Sanjan Plant (Gujarat)

In 2014, another state of art plant inSanjan was set up Our Sanjan Plant, is the largest plant of its kind in South-east Asia with an installed capacity of over 1,000 units per day With Fully Automated Paint Shop, Fully Automated Foaming Plant, & Backward integrated facility of in-house Shelf Production, Coil Production, Wire Harness Production this plant has capacity of;

Annual Production capacity 275000 units.
Peak capacity per month 23000 units.
4 manufacturing lines.

Today with these 3 State-of-Art plants, Western is leading Manufacturer in India

YOU DESERVE THE BETTER

WESTERN even today continues to have a thriving Importing & Trading Business, a business which is very close to our heart as it is based on one of our guiding objective of providing a one Stop Shop for our customers.

Health, Safety and Environment

We at Western believe in making a positive impact on society by ensuring compliance to Environment, Health and safety regulations.

View

CSR Policy

The main objective of this policy is to make CSR a key business process for sustainable development of the society. It lays down the guidelines and mechanism for undertaking CSR programmes in alignment with the Section 135 of the Companies Act 2013. To directly/indirectly undertake projects/programs, which will enhance the quality of life and economic well-being of the communities, in and around our business operation units and the society at large.

Download

Western Group Journey

NOW

2014

New plant in Gujarat with capacity of 1,000 units per day when fully commissioned.
2013

Partnership with Hoshizaki Corporation - Japan
1999

Second plant for manufacturing Visi-Coolers and Deep freezers was set up
1997

First plant for manufacturing Visi-Coolers exclusively for Coca-Cola was set up in Shahpur
1991

WESTERN Group diversified into the fast growing Beverage Dispensing and Commercial Refrigeration Equipment Industry.
1972

Western Group came into Existence. Operations in trading and imports of refrigeration & air conditioning equipment

Hoshizaki Corporation

Western Partnered with Hoshizaki Corporation in year 2013
HOSHIZAKI Corporationwas started by Mr. Shigetoshi Sakamoto in 1947.
It is today located in Toyoake, Aichi, Japan and is headed by Mr. Seishi Sakamoto, Chairman
Worldwide Hoshizaki Group comprises of 46 affiliated companies with over 11,000 employees
Core business includes Manufacturing & Sales of commercial Kitchen equipment, Show-cases & Dispensers

Scroll

	330ml cans	500ml Pet
Capactity	166 nos.	83 nos.
Facing	06 nos.	06 nos.

Container Loading	20’ FCL	40’ FCL
	27 units	60 units

	Western Refrigeration Pvt. Ltd. Office Premises 501, 502, 503, 504, 505, 5th Floor, Ascot Centre, Sahar Road, Next to Hotel Hilton, Andheri (East), Mumbai – 400 099.
	+91 22 - 67161200
	+91 22 - 67161294
	sales@westernequipments.com
